The industry standard in high-rate sand filtration for residential in-ground and above-ground pools. Engineered from rugged, weather-proof polymeric material, the Hayward ProSeries top-mount sand filter delivers crystal clear water filtration with minimal maintenance. Features Hayward's legendary 7-position VariFlo™ control valve with integral sight glass for rapid, hassle-free backwashing.
Technical specifications
| Warranty | 2026 EXPERT LINE® RESIDENTIAL WARRANTY TERMS All Products* Exceptions listed below In Ground Standard Parts 3 Years Field Labor 1 Year Source: Hayward warrantyWarranty is provided by the manufacturer under its own terms. See the source link for full details. |
|---|
Key features
- Durable polymeric tank body — corrosion-proof, single-piece molded spherical tank designed for maximum strength under severe Ontario winter freeze-thaw cycles.
- 7-position VariFlo™ control valve — intuitive lever action selector easily dials Filter, Backwash, Rinse, Waste, Closed, Recirculate, or Winterize modes.
- Self-cleaning 360-degree slotted laterals — umbrella-fold lateral design maximizes balanced flow and deep bed filtration for crystal-clear clarity.
- Integral sight glass & pressure gauge — visual backwash indicator and heavy-duty pressure dial make routine maintenance straightforward.
- Large pressure sand/water drain — rapid winterization and quick media changeout with easy bottom drain plug.
Specifications
| Brand | Hayward |
|---|---|
| Series | ProSeries Top-Mount |
| Filtration type | High-rate granular sand / glass media filter |
| Tank material | Corrosion-proof molded polymeric chassis |
| Control valve | Hayward 7-position VariFlo™ valve (1.5 in / 2.0 in connections) |
| 18 in (S180T) capacity | 125 lb sand • 35 GPM design flow rate • 16,800 gal 8-hr turnover |
| 21 in (S210T) capacity | 200 lb sand • 44 GPM design flow rate • 21,120 gal 8-hr turnover |
| 24 in (S244T) capacity | 300 lb sand • 62 GPM design flow rate • 29,760 gal 8-hr turnover |
| 27 in (S270T) capacity | 350 lb sand • 74 GPM design flow rate • 35,520 gal 8-hr turnover |
| 30 in (S310T) capacity | 500 lb sand • 98 GPM design flow rate • 47,040 gal 8-hr turnover |
| Maximum working pressure | 50 PSI (3.45 bar) |
Before you buy
- Media requirement: Standard #20 silica sand (0.45 – 0.55 mm) or recycled glass media required. Media sold separately.
- Plumbing size: 18-inch and 21-inch models use 1.5-inch plumbing; 24-inch, 27-inch, and 30-inch models support 2-inch plumbing for high-flow variable-speed pumps.
- Winterization: Drain completely before first freeze; turn VariFlo valve handle to the "Winterize" setting between notches.
Documents
Frequently asked questions
What size Hayward sand filter do I need for my Ontario pool?
Tank diameter depends on your pool volume and pump flow rate. The 18-inch S180T suits pools up to 16,800 gallons; the 21-inch S210T handles up to 21,120 gallons; the 24-inch S244T covers up to 29,760 gallons; the 27-inch S270T supports 35,520 gallons; and the 30-inch S310T handles large estate pools up to 47,040 gallons based on standard 8-hour turnover calculations.
Can I use recycled glass filter media instead of standard silica sand?
Yes. Hayward ProSeries sand filters are fully compatible with recycled glass filter media as well as standard #20 silica sand (0.45 to 0.55 mm). Glass media filters down to 5 to 9 microns (compared to 20 to 40 microns for silica sand) and requires approximately 20% less media by weight.
How do I winterize a Hayward ProSeries sand filter for Ontario winters?
To protect the tank lateral assembly against Ontario sub-zero freezing, remove the bottom drain plug and open the air relief valve to drain all water. Remove the pressure gauge and sight glass, then rotate the VariFlo valve handle to the "Winterize" setting (between active detent notches) to allow water to drain from the valve body.
How often does filter sand need to be replaced?
Under typical Ontario seasonal pool usage (May to September), standard #20 silica sand lasts 3 to 5 years before the sand grains become rounded and channelled. Recycled glass media typically lasts 8 to 10 years before requiring changeout.
Specifications from Hayward Pool Products engineering documentation.
